Prime RES - KIT

CLM-Pro-Prime-RES-RC-model1

Prime RES - KIT

RatingNot Rated Yet
Base price $297.00
Base price with tax
Sales price $237.00
Sales price without tax $237.00
Discount $-60.00
ManufacturerCLM Pro
Description

Unassembled pure glider KIT version - according to FAI F3 RES competition rules. Prime RES has 2m / 78.74" wingspan. Total model weighs ARC 300 grams / 10.58 oz. Laser cut ribs and all other required parts.

CLM Pro has released a new model called Prime RES. The model is designed and produced according to FAI F3-RES competition rules.
The model is designed and optimized to the last detail and it all comes together perfectly. Most importantly, when flying and competing, adjustments can be done quickly on the spot (ballast, hook etc.)
All parts are precisely laser-cut from balsa and aero plywood, all carefully selected high-quality materials.
Due to its aerodynamic design and excellent performance, it is very stable and is a joy to fly.

Prime RES is a model for competitions, made according to FAI F3-RES rules.

As the name says, the "Prime" model has, among other things a few new features and details, which include:

* an adjustable hook: you can change the position of the hook (forward-backward) in the field in a second
* safety mechanism for the joint between wing segments - no more glueing with tape on joints and other improvisations: one click and the wing is attached
* ballast: integrated box in the pod, with a few reserve ballast modules, which can be changed in the field in literally two seconds without disassembling the model
* angled carbon wing joiners mean there is no complicated crafting of the box for the joiner in the wings. You receive everything ready in the kit.
* other details worked out to the last bit

Kit includes:
- detailed drawing in color
- detailed building manual with step-by-step images
- CNC cut jig from styrofoam (underside of wings) for easier wing glueing
- laser cut ribs and all other required parts
- carbon tailboom
- carbon tube for mainspar with kevlar wrapped where wing joiners go
- carbon wing joiner and other carbon small parts
- vitroplast safety mechanism for locking the wing segments in place
- adjustable tow hook, including all necessary parts
- rudder horns, u-nuts and various bolts for mounting
- various magnets for the spoiler, ballast box and other
- bowdens and controls for connecting moving surfaces

Additional details for each segment of the model can be found below.

Wings:

The wing is constructed so that the centerpanel is straight, while the middle panel and tip panels are angled. The wing is constantly an elipsis throughout its length which gives the model good stability and easy handling during flight.
The centerpanel is made as a single segment, the mid panel is another segment, and the two are joined with carbon joiners and have pre-prepared pins so that everything fits together perfectly.

An innovative advantage is the safety mechanism for the joint between wing segments - no more glueing with tape on joints and other improvisations: one click and the wing is attached.
Second advantage on the build is a pre-prepared wing carbon joiner made at an angle, so there is no complications of makin the joiner box in the wing.
Kits also includes a carbon tube which is used as mainspar, and is reinforced with kevlar where wing segments are connected.
You also get a CNC cut styrofoam jig for easier wing glueing.

The main construction of the wings is built with full balsa ribs, plywood for trailing edge and reinforcements where needed, while composite materials are used for leading edge and mainspar according to FAI rules.
All parts are laser cut and fit together perfectly. So there is minimum rework needed, you only have to assemble everything and bond according to the manual.
The centerpanel comes with a spoiler with built-in magnets so its perfectly closed when in closed position.

CLM Pro Prime RES wings 2  CLM Pro Prime RES wings 4 Prime RES wings

Fuselage:

As our every fuselage, this fuselage is also made with aerodinymical shape with smooth transitions. Again, all parts are laser cut out of alsa and avio plywood.
The fuselage is reinforced on strategic spots with selection on material which gives it more strength.

One of the main features is also adjustable tow hook which is made of several parts which allows you to change the position of the hook (forward-backward) in the field in a second.

Special attention was also given to the ballast, which is integrated within a box in the pod, with a few reserve ballast modules, which can be changed in the field literally in seconds without disassembling the model.

Canopy is designed in a way that there is enough space to easily manipulate with all components in the pod, allowing the battery to be inserted and connected easily, improving usability on the field.
The canopy has a mechanism with magnet for easier closing and making sure that it will not fall off during flight.

The tappered carbon tailboom is made from several carbon types. Materials are strategicaly oriented, so the boom has maximum strength and minimum weight.

The front of the pod is made in such a way that it can easily be converted to electro version. You get neccessary parts for both glider and electro version.

CLM Pro Prime RES fuselage 1 CLM Pro Prime RES fuselage 4 CLM Pro Prime RES fuselage 5

Tail:

The tail is also designed having aerodynamics in mind. It is a construction of lase cut balsa components. The connection between horizontal and vertical stab is reinforced with carbon.

Horizontal stab/elevator is fied to the tailboom via pylon which has a built-in nut so the tail can be dissasembled for easier transport.

Vertical fin has pre-prepared carbon pins which are inserted into drilled tailboom and is easilly fied to the fuselage.

CLM Pro Prime RES tail 1 CLM Pro Prime RES tail 2 CLM Pro Prime RES tail 3

We used A-tested resin, certified for aeroplane construction for all parts made od composite material.

Note: You can also order foil for model covering. We only use the highest quality Oralight foil from the German manufacturer Lenitz Prena Oracover Oralight.

These are the colors you can choose from: https://www.clm-pro.com/store-detail/covering-material



file type pdf icon 130274 Prime RES Build Manual can be downloaded here (download will start automatically)





Recommended glider setup:
Servo rudder / elevator: EMAX ES08MA II
Servo spoiler: EMAX ES9051
Battery: LiIon-Akku 1S/260mAh; 2S LiPo-Akku 300-850mAh; NiMh-Akku 300-700mAh
Receiver: 4 or 5 channel receiver to match your transmitter

Recommended electric setup:
Servo rudder / elevator: EMAX ES08MA II
Servo spoiler: EMAX ES9051
Powertrain: Torcster Brushless Blue A2225/19-1350 32g
ESC: ZTW MANTIS Slim 15A
Battery: 3S 450-600mAh
Spinner: 30 mm / 1.18"
Prop: 8x5"
Receiver: 4 or 5 channel receiver to match your transmitter



Prime RES specifications:

Wingspan:

1960 mm

77.16"

Length:

1256 mm

49.44"

Wing area:

35 dm2

 542 sq. in.

Airfoils:

AG 24-26 mod

AG 24-26 mod

Weight structure:

300 g

10.58 oz

Weight covered:

380 g

13.40 oz

Flying weight from:

470g

16.57 oz

Control surfaces:

RES

RES

CoG: 67 - 73 mm / 2.12” - 2.48”



Prime RES weight of parts:

Fuselage

75g

 2.64 oz

Tailboom

20g

 0.70 oz

Rudder / vert stab - covered

8g

 0.28 oz

Elevator / hor stab

14g

 0.49 oz

Center panel

95g

 3.35 oz

Tip panel

45g

 1.58 oz

Carbon joiner

6g

 0.21 oz

Bolts

5g

 0.17 oz

Bowdens

10g

 0.35 oz

Accessories

25g

0.88 oz
